Role of I-scan in Diagnosis of Duodenal Mucosal Lesions during Gastroduodenoscopy

INTRODUCTION
Duodenal mucosal lesions are usually difficult to diagnose. White light ‎endoscopy (WLE) commonly does not visualize the duodenal villous patterns properly ‎and miss small raised lesions, which result in imprecise diagnosis [1]. In duodenal ‎lesions the different damage can have a sporadic distribution, and the macroscopic ‎features can be almost related to the degree of the histological lesions [2].‎
Indeed, at WLE partial villous atrophy may be missed and the normal mucosa ‎appearance at endoscopy does not necessarily mean normal histology. Numerous ‎endoscopic features observed during WLE reveal the villous atrophy presence [3, 4]. ‎Recently, a biopsy strategy only for patients with villous atrophy detected while using ‎image enhancement techniques, has been proposed [5].‎
Duodenal carcinoma (DC) is considered a rare gastrointestinal malignancy. ‎Duodenal polyps, either ampullary or non-ampullary adenoma, can be the cause of the ‎development of DC. Some ampullary neoplasms may be early presented with ‎obstructive jaundice or pancreatitis, when a small lesion causes obstruction of ampullary ‎orifice, while nearly all non-ampullary  neoplasms  are incidentally detected through ‎endoscopy for other causes [6, 7]. Nearly all non-ampullary neoplasm presented with ‎gastrointestinal bleeding or bowel obstruction, are usually diagnosed at an advanced ‎stage with bad prognosis [8]. Early detection is needed for improving the survival.
Developed visual endoscopic techniques can detect suspected duodenal mucosal ‎lesions or atrophy; lead to better targeting of the biopsy taking and sensitivity improving ‎of the endoscopy [9]. Various emerging techniques have been tested, alone or in ‎combination, to improve the endoscopist ability to detect mucosal anomalies and to ‎more accurate image the villi architecture, as water immersion, narrow band imaging, I-‎Scan, high definition-zoom magnification, optical coherence tomography, ‎chromoendoscopy system, and confocal laser endomicroscopy [10, 11].‎
I-scan is Japanese technology settled by Pentax Medical Company for image ‎enhanced by endoscopy. It can be categorized among digital contrast techniques. It ‎permits three distinct image enhancement modalities; they are surface enhancement ‎‎(SE), contrast enhancement (CE), and tone enhancement (TE). This technology is an ‎imaging post-processing technique, which analyses in real time the endoscopic images ‎without dye practice. It can be achieved just by a button pressing on the endoscope, ‎which it enables the endoscopist to change between the various setting modalities [12].‎
The aim of this study was to determine the diagnostic accuracy of I-scan ‎technology for evaluation and histological confirmation of mucosal lesions in ‎duodenum and it's role in biopsy targeting in cases admitted to tropical medicine ‎department.‎

PATIENTS AND METHODS
I- Patients
This study was conducted on 41 patients (25 males and 16 females), their ages ranged from 9 to 65years old, who were seen at the Tropical Medicine Department, Faculty of Medicine, Zagazig University Hospitals. Patients were presented with undiagnosed iron deficiency anemia cause, progressive weight loss, chronic diarrhea or persistent abdominal pain. We excluded severe gastric abnormalities, severe hepatic diseases, blood coagulation disorders and failure to complete esophagogastro-duodenoscopy.
II- Methods
All patients were subjected to complete history taking and clinical examination. We stressed on the possible causes of weight loss, dyspepsia, abdominal cramps and chronic diarrhea. We examined the abdomen for epigastric tenderness, organomegally and palpable mass. Laboratory investigations were assessed as complete blood picture, liver function test: alanine amino transferase (ALT), aspartate aminotransferase (AST), serum albumin, total and direct bilirubin by routine enzymatic methods (spinreact), Anti-tissue transglutaminase (Anti TG-Ig A) and endomysial antibodies (EMA). Pelvi-abdominal Ultrasound was done to detect organomegally, abdominal mass, and exclude chronic liver disease [13]. Upper GIT endoscopy was done using Pentax video endoscopy unit in association with I-Scan techenology imaging with high resolution view. 4 to 6 guided biopsies by I-Scan were taken from the duodenum (in duodenal folding or interfolding) at potential atrophy sites and when disorder was suspected, which were histopathologically examined.
Endoscopic Procedures
All procedures were done by using I-scan technology included in a Pentax EPK-I processor and EG-2985K. This instrumentation delivers high-resolution images with adjustable digital image magnification over.  For this study, we concentrate on the third set of I-scan mode. Patients were sedated with up to 5 mg of midazolam intravenously before undergoing endoscopy. Alternatively, the children were sedated with midazolam 0.1mg/kg intravenous administration. All endoscopies were completed by experienced endoscopists. All subjects underwent a careful endoscopic duodenal inspection. The procedure was started with an initial evaluation of the duodenal mucosa by WLE. On the mucosal surface, any debris was removed. In all cases, examination is carried out up to the second part of the duodenum. The features of duodenal mucosal folds, including atrophy, scalloping, and nodularity and any surface lesions such as polyp, nodule, or tumor were determined. Duodenal ampulla was also examined. Then, the endoscope switched to I-Scan mode. The three I-scan sets, from set 1 to set 3, were used serially, spending an average time of 15 s per single I-scan set. Finally, from the duodenum, directed biopsies were taken.
Histopathology
Endoscopic biopsies collected in small sterile bottle filled with formalin and transported to the pathological evaluation by expert pathologist within 2h. Several steps were done to preserve, harden, and protect the tissue from shrinkage. They included Fixation, Dehydration, Clearing, Wax Infiltration, Embedding and Blocks were sectioned at 3–4 micron thickness and were stained with routine hematoxylin and eosin stain.
Statistical analysis
Social Sciences (SPSS version 20.0)) software Statistical Package for analysis was used. According to the type of data, qualitative data represented as number and percentage and quantitative data represented by mean ± SD. Sensitivity, specificity & predictive value were used to assess the validity in the diagnosis.  McNemar and Chi-square test (X2) were used to find the association between different variables.

RESULTS
‎41 patients were included , the age mean was 39.9 years. The majority were males ‎‎61%. Abdominal pain was the main symptom of presented patients 75.6% with or ‎without other complaints. There was a significant association between disease diagnosis ‎by (I-scan) and abdominal pain (p < 0.026). 34.1% of patients had normal examination ‎and 46.4% of them had epigastric tenderness. Laboratory results, including liver ‎function and CBC parameters were normal regarding mean and range, while the Hb ‎level showed a wide range from 7.5-15.6 gm/dl. Anaemia was diagnosed in 36.5% of ‎studied patients, most of cases were microcytic hypochromic (34.1%), but there was no ‎significant association between disease diagnosis by (I-scan) and anemia table (1). ‎
Histopathological examination was the gold standard to investigate the taken ‎biopsied specimens, which result the following diagnosis: 5cases were normal, 3 cases ‎were celiac, one case was eosinophilic gastroenteritis (duodenum and stomach), 29 ‎were chronic duodenitis, 2 were H. pylori duodenitis and one case was duodenal bulb ‎adenoma summarized in table (2). 25% of suspected celiac patients had negative ‎serology, while 75% of them were anti-TG IgA positive. This table shows that by ‎WLE, 36.6% of the study patients were normal and 51.3% had duodenitis while by I-‎scan 14.6% were normal and duodenitis appeared in 68.3% of cases. Duodenitis ‎appeared in the form of superficial ulceration, diffuse mucosal nodularity, severe ‎mucosal congestion and mucosal edema.‎
Mucosal duodenal lesions in our study patients by I scan viewed as table (3) ‎‎48.8% of the studied patients were normal, 9.7% were PVA, 2.4% were polyps, 4.8% ‎were Ulcers, 14.6% were Nodules, 14.6% were fibrous erosion and 4.8% were ‎abnormal sub mucosal lesions (Accentuated elevation with prominent mucosal ‎architecture with distant mucosal abnormalities), while vascular changes viewed as ‎increased with surface enhancement in 63.4% of cases fig (1, 2).‎
Overall diagnostic accuracy of I scan was 90.2% (95% CI) and that of WLE ‎was 68.3% (95% CI), sensitivity and specificity 91.9% and 75% (95% CI) for I scan ‎and 67.6% and 75% (95% CI) for WLE. PPV and NPV to diagnose (or to exclude) ‎were 97.1% and 50% (95% CI) for I scan and 96.1% and 20% (95% CI) for WLE. ‎Diagnostic accuracy to diagnose celiac for I scan was 95.1 (95% CI) and that of WLE ‎was 92.7% (95% CI), sensitivity and specificity were 75% and 97% (95% CI) for I scan ‎and 25% and 100% (95% CI) for WLE table (4, 5).‎

DISCUSSION
In order to obtain images and enhance image contrast through post-processing ‎algorithms, I-Scan technology uses various reflective properties for normal and diseased ‎tissues [14]. Without the use of dyes, I-scan enhances the contrast of the mucosal ‎surface and bypasses the problems associated with conventional chromo-endoscopy by ‎providing the ability to increase the contrast or 'colour' of the surface in less than a ‎second, just by i-scan button pressing related to the particular feature [15], It can ‎contribute more precise topography of the mucosal surface, and delineate lesion edges ‎by improving vessel and minute mucosal structures [16]. To our knowledge, I-Scan ‎technology has not been considerably tested enough to determine duodenal mucosal ‎lesions.‎
In our study, 41 patients were included (25 male, 16 females, mean age 39.9, ‎range 9–65 years).As regards clinical presentations, abdominal pain was found to be the ‎most common presentation (78%), while pallor (7.3%), diarrhea (7.3%), Melena (2.4%) ‎and Dyspepsia (2.4%).In our study, we found that there is a significant association ‎between the diagnosis by I-scan and abdominal pain. This was different from ‎Cammarota and et al, who found that out of 115 patients, 32 patients was presented ‎with diarrhea, 31 with abdominal pain, 27 with iron deficiency anemia and 19 patients ‎were presented with weight loss. This difference was due to that our study assessed role ‎of I-scan in all duodenal mucosal lesions while Cammorata assessed the role of I-scan in ‎evaluation of duodenal villous pattern and his study included many patients with ‎diagnosed celiac disease and underwent endoscopy for follow up.‎
In our study, all routine laboratory investigations were normal, except ‎hemoglobin level show wide variety with range 7.5- 15.6 gm/dl. In our study, there was ‎no association between anemia prevalence and diagnosis of duodenal mucosal lesions ‎by I-scan. Our results was conceding with those of Gonen, et al and other study, who ‎studied the diagnostic yield of routine duodenal biopsies in iron deficiency anemia for ‎the diagnosis of celiac disease and the value of duodenal biopsy within routine upper ‎endoscopy, respectively. They found that there was no association between anemia ‎prevalence, and the endoscopic diagnosis of celiac disease or giardiasis [18, 19].‎
Serology evaluation of celiac disease showed positive anti-tissue anti-‎transglutaminase IgA antibody and EMA in 3 cases who after that confirmed CD by I- ‎Scan and pathology. Our result was similar to that of Zamani F and et al, who ‎presented proof that together tTG and EMA should be used for CD diagnosis, although ‎some recommendations suggested that only EMA or tTG is sufficient to diagnose CD ‎patients [20,21]. Schyum and Rumessen also had shown that tTG IgA and DGP IgG ‎have the best clinical diagnostic results, but it is early to endorse a diagnostic approach ‎for CD in adults that omit duodenal biopsy. In our opinion, use of I-scan targeting ‎biopsies will be of value in such cases [22]. ‎
Dutta and Chacko divided I-Scan morphological patterns among the study ‎patients into mucosal and vasculature' changes. As in villous morphology assessment, ‎both surface and vascular features are essential for the evaluation of the neoplastic lesions ‎‎[23]. Vascular pattern changes and developed angiogenesis are features of neoplastic ‎changes in the tissue. In our study, we use the same classification (mucosal and ‎vascular). The mucosal lesions were distributed as normal, PVA, polyps, ulcers, ‎nodules, fibrous erosion, and abnormal sub mucosal lesions (Accentuated elevation ‎with prominent mucosal architecture with distant mucosal abnormalities), while ‎vasculature changes were classified as normal and abnormal (Increase with surface ‎enhancement).‎
Our results regarding histopathological examination: 70.7% of the biopsies were ‎chronic duodenitis, 7.3% celiac, 4.8% H pylori duodenitis, 2.4% for eosinophilic ‎duodenitis and adenoma, while 9.8% were normal.‎
I-scan image enhancement technology showed positive endoscopic findings and ‎abnormal pathological changes in 35 patients. I-scan technology resulted in diagnosis of ‎‎3 cases of celiac disease, 1 case of esinophilic duodenitis, 1case of duodenal adenoma, ‎‎2 cases of H. pylori duodenitis and 29 cases of chronic duodenitis. I-scan in our study ‎was helpful in diagnosis of 2 cases of H. pylori duodenitis. Most of the I-scan studies in ‎the gastrointestinal tract focused on the esophagus and colon for Barrett's esophagus ‎evaluation and colorectal polyp detection. Comparatively little information is available ‎on its usefulness in the assessment of duodenal pathology, especially in H. pylori. ‎However, recent study by Balekuduru and et al., investigated I-scan value in the ‎detection of features similar to H. pylori infection. In that study, 68 patients presented ‎with functional dyspepsia examined by M-WLE and I-scan. H. pylori infection ‎detection was based on surface vascular features. As a reference gold standard, gastric ‎biopsies were used in detection of H. pylori infection, the sensitivity and specificity I-‎scan were more than 90% [24]. ‎
We have demonstrated a number of patients in which I-scan can be clinically ‎beneficial and affect patient care. It was helpful in diagnosis of a case of duodenal bulb ‎adenoma, who was 42 years old male presented at emergency room by melena, WLE ‎showed slight elevation in duodenal bulb while I-scan showed accurate detection of the ‎mass in duodenal bulb with its boundaries with abnormal mucosal architecture and ‎surface breaks. Testoni and et al studied I-scan in comparison to conventional ‎colonoscopy and they showed higher detection rates of non-protruding adenomas less ‎than 10 mm [25]. However, another study evaluated I-scan's ability in small polyps (< ‎‎10 mm) detection to assist in the accurate assessment of polyp histopathology; they ‎found no significant difference between both techniques in histology prediction. ‎
In our study, the validity of I-scan as a diagnostic test was 90.2% accuracy (95% ‎CI were from 76.87% to 97.28%), 91.9% sensitivity, 75% specificity, 97.1% PPV and ‎‎50% NPV compared to WLE, which achieved 68.2% accuracy (95% CI were from ‎‎51.91% to 81.92%),  67.6% sensitivity, 75% specificity, 96% PPV and 20% NPV. Our ‎result was in agreement with Hancock and et al who studied the uses of I-scan and ‎concluded that it helped in the diagnosis of  neoplastic changes as Barrett‘s esophagus, ‎gastric lymphoma, duodenal adenoma and lymphoma [16]. ‎
In our study, I-scan achieved 95.1% accuracy, 97% specificity, 75% sensitivity ‎in the diagnosis of celiac disease and detection of duodenal villous atrophy compared to ‎WLE that achieved 92.7% accuracy, 100% specificity, 25% sensitivity. In WLE this ‎may be due to poor sensitivity of mucosal fold changes such as atrophy, scalloping and ‎nodularity compared to histology and similar cause was concluded by Banerjee and ‎Reddy [27]. Our results were closely near the findings of Cammarota and et al [17]‎‎, who  reported that I-scan achieved excellent outcomes in the depiction of duodenal ‎villous patterns, and reached 100% accuracy in diagnosis marked villous atrophy, 90% ‎accuracy, 77% sensitivity and 94% specificity in (PVA pattern) in celiac disease.‎

CONCLUSION
Our findings show that I-scan represents a simple technique that help in the ‎diagnosis of duodenal mucosal lesions with sensitivity 91.9%, specificity 75% and ‎accuracy 90.2% by providing detailed mucosal topography especially in patients ‎presented by abdominal pain, which can directly impact endoscopic management and ‎importantly improve biopsy sampling so, potentially reducing the need for blind ‎biopsies and false-negative cases‎.‎
Declaration of conflicting interests: None
Funding: None
Ethical approval: Written informed consent was obtained from all patients and IRB approval.‎
